| SPECIFICATIONS | |
| Material | R-pet + GF |
| Extrusion speed | 0,4 m/min |
| Dimensions of profile | 194x194 mm |
| Main wall thickness | 4 mm |
| Meter weight | ~ 6 kg/m |
| MACHINERY DATA | |
| Extruders | Single-screw extruder |
| Calibration table | |
| Tooling | Die / Dry calibrator / Blinds / Vakuum tank |
| Haul-off | Caterpillar haul-off |
| In-line profile processing | no |
| Cutting device | Saw |
| Stacking | Tipping table |
| SPECIFICATIONS | |
| Materials | R-pet + GF |
| Extrusion speed | 0,4 m/min |
| Dimension of profile | 200x112,5 mm |
| Main wall thickness | 4 mm |
| Meter weight | ~ 6,5 kg/m |
| MACHINERY DATA | |
| Extruders | Single-Screw extruder |
| Calibration table | |
| Tooling | Die / Dry Calibrator / Blends / Vakuum tank |
| Haul-off | Caterpillar haul-off |
| In-line profile processing | no |
| Cutting deivce | Saw |
| Stacking | Tipping table |
